Charm EZ System

Charm EZ System
Rapid Testing for Antibiotics in Milk

Superior Science

The Charm EZ system instantly identifies test strip color and automatically adjusts incubation time, temperature, and test calibration to match.

Hands-Free Testing with Combined Incubator/Reader

Analyzes test strip automatically once the incubation is complete
Allows batching of external tests with multiple ROSA quad incubators for high volume users

Touch-Screen

Streamlines operation by giving the user the ability to quickly enter and select appropriate information

Printable or Downloadable Results

Backs up 8000 test results to internal memory, and the SD card stores over 100,000 test results
Transmits results to a PC wirelessly or by using a standard USB cable, or to a LIMS network over Ethernet
Exports to Excel for analysis

Sample ID

Recognizes sample ID input through the touch screen, an external keypad, an RFID, or a bar code reader

Maximize your Investment

One Instrument, Multiple Tests: The Charm EZ system's unprecendented versatility allows for a variety of different antibiotic tests to be run with a single instrument.

Beta-lactam

Charm 3 SL3 Charm 3 SL3 Beta-lactam
SLBL Beta-lactam at SLB
MRLBL1 Beta-lactam, 1-minute at MRLC
MRLBL3 Beta-lactam, 3-minutes at MRL

Aflatoxin

SLAFMQ Aflatoxin M1, Quantitative at SL
MRLAFMQ Aflatoxin M1, Quantitative at MRL

Other Antibiotics

STREP Streptomycin
NEO-STREP Neomycin and Streptomycin
CHLOR Chloramphenicol
QUIN Quinolones
SULFA Sulfonamines
TET Tetracycline

QUADS

Russian Regulations Beta-lactam, Tetracycline, Streptomycin and Chloramphenicol at Custom Union Levels
QUAD1 Beta-lactam, Tetracycline, Sulfa Drugs, Quinolone at MRL
QUAD2 Macrolides-(Tylosin, Lincosamide, Erythromycin, Tilmicosin) and Gentamicin at MRL
QUAD3 Aminoglycosides-Neomycin, Streptomycins, Kanamycin and Spectinomycin at MRL

COMBO

FLUSLBL Flunixin and Beta-lactam
MRLBLTET Beta-lactam and Tetracycline at MRL
MRLBLTET2 Beta-lactam and Tetracycline, 2-minutes at MRL
MRLBLRFTET2 Beta-lactam and Tetracycline, Customs Union countries (Russia, Kazakhstan, and Belarus) at MRL
TRIO Beta-lactams, Sulfonamides,and Tetracyclines

Rapid Testing for Antibiotics in Milk

The Charm EZ® is a complete simultaneous incubator and analyzer system specifically designed for use with the new color coded Charm® lateral flow tests, Charm 3 and Charm ROSA® test strips. The Charm EZ system is equivalent to the ROSA Pearl reader and may be used with US-approved screening methods in compliance with NCIMS (refer to FDA M-I-13-2). Charm EZ system may be used in either a “read only” mode or an “incubate and read” mode. In a “read only” mode the test is performed in an external incubator and then read in the Charm EZ system. In the “incubate and read” mode the test is performed with the built in incubator and automatically monitored and read at the end of incubation. Results are interpreted based on a numerical scale and stored in the Charm EZ system memory. Data are displayed on the Charm EZ system screen, can be printed to an external printer and downloaded to a computer system in a real time or post analysis mode. EZ Export is required to download data to a computer.

The Charm EZ system American Test Configuration is programmed for performing NCIMS approved Charm methods. The tests supported are as follows:

Charm 3 SL3 Beta-lactam Test
Charm SL® Beta-lactam Test
Charm Flunixin and Beta-lactam Test
Charm SL Aflatoxin M1 Quantitative Test 0-500ppt
Charm Chloramphenicol Test
Charm Sulfa Test
Charm ROSA Tetracycline-SL (Dilution Confirmation) Test
Charm Streptomycin Test
Charm Quinolone Test
Charm TRIO® Test

Contact Charm for other available ROSA tests not listed above.

Specifications

Unit Dimensions	17 x 16.4 x 7 cm (W x H x D)
Weight:	0.5 kg
Screen Dimensions:	5.6 x 7.3 cm (W x H)
Screen Display:	64 bit, LED backlighted color 8.9 cm display
User Interface:	Touch Screen
Power Source (AC):	12 V DC Adapters for 110 V / 60 Hz or 220 V / 50 Hz
Auto Adapters:	12 V DC and 24 V DC (with converter)
Calibration:	Factory Set (controls available for verification)
Memory Capacity:	100,000 Tests
Data Port:	USB and SD card slot
Data Output:	Test ID, Sample ID, Operator ID, Test Result, Temperature, Date and Time
